Electrochemical magnesium ion intercalation chemistry of MoO3 has been studied in this work. Submicron-sized MoO3 has been synthesized from commercial micron-sized MoO3 by a facile oxalic acid method, which was confirmed by SEM and XRD. A beaker-type three-electrode measurement cell was designed using activated carbon as the counter electrode, which enabled the test of magnesium intercalation into the host material at the working electrode without problem when conventional organic electrolytes are used. The electrochemical magnesium intercalation into MoO3 has been confirmed by cyclic voltammetry, galvanostatic discharge/charge, powder XRD and EDS measurements. Reversible reduction and oxidation peaks were obseved in cyclic voltagramms as well as discharge/charge cycles, corresponding to magnesium insertion and deinsertion, respectively. The reversibility was also confirmed by XRD measurement which also showed that a new phase is formed during the discharge and the discharge/charge processes are a pseudo two-phase reaction. With cycles, a degradation in crystallinity was observed. ⓒ 2014 DGIST
Table Of Contents
1.Introduction 1 -- 1.1 Principle of Magnesium battery 4 -- 2. Experiments 5 -- 2.1 Synthesis of submicron-sized MoO3 5 -- 2.2 Preparation of electrodes and electrolyte, and materials characterization 5 -- 2.3 Electrochemical cell configuration and characterization 6 -- 3. Results and Discussion 9 -- 3.1 Materials preparation 9 -- 3.1.1 Synthesis of submicron-sized MoO3 9 -- 3.2 Galvanostatic measurements 11 -- 3.3 Structural change during first magnesium insertion process 14 -- 3.4 Structural change during first magnesium de-insertion process 17 -- 3.5 Cyclic voltammetry of MgxMoO3 20 -- 4. Conclusions 22 -- References 24 -- 요약문 25 -- Acknowledgement 27
Research Interests
Magnesium; calcium; and zinc ion batteries; lithium all-solid-state batteries; Inorganic materials discovery; Solid state chemistry; Crystallography; Mg; Ca; Zn 이온 이차전지; 리튬 전고체전지; 신 무기재료 합성; 고체화학; 결정화학
