The impact of electrode materials on 1/f noise in piezoelectric AlN contour mode resonators

Title
The impact of electrode materials on 1/f noise in piezoelectric AlN contour mode resonators
Authors
Kim, Hoe JoonJung, Soon InSegovia-Fernandez, J.Piazza, G.
DGIST Authors
Kim, Hoe Joon
Issue Date
2018-05
Citation
AIP Advances, 8(5), 055009
Type
Article
Article Type
Article
Keywords
Aluminum nitrideDampingIII-V semiconductorsPiezoelectricityResonatorsThermoelasticityAluminum nitride (AlN)Contour-mode resonatorsExpansion coefficientsMechanical structuresPower-law dependencesRadio frequency applicationsThermoelastic dampingTop-electrode materialsElectrodes
ISSN
2158-3226
Abstract
This paper presents a detailed analysis on the impact of electrode materials and dimensions on flicker frequency (1/f) noise in piezoelectric aluminum nitride (AlN) contour mode resonators (CMRs). Flicker frequency noise is a fundamental noise mechanism present in any vibrating mechanical structure, whose sources are not generally well understood. 1 GHz AlN CMRs with three different top electrode materials (Al, Au, and Pt) along with various electrode lengths and widths are fabricated to control the overall damping acting on the device. Specifically, the use of different electrode materials allows control of thermoelastic damping (TED), which is the dominant damping mechanism for high frequency AlN CMRs and largely depends on the thermal properties (i.e. thermal diffusivities and expansion coefficients) of the metal electrode rather than the piezoelectric film. We have measured Q and 1/f noise of 68 resonators and the results show that 1/f noise decreases with increasing Q, with a power law dependence that is about 1/Q4. Interestingly, the noise level also depends on the type of electrode materials. Devices with Pt top electrode demonstrate the best noise performance. Our results help unveiling some of the sources of 1/f noise in these resonators, and indicate that a careful selection of the electrode material and dimensions could reduce 1/f noise not only in AlN-CMRs, but also in various classes of resonators, and thus enable ultra-low noise mechanical resonators for sensing and radio frequency applications. © 2018 Author(s).
URI
http://hdl.handle.net/20.500.11750/6415
DOI
10.1063/1.5024961
Publisher
American Institute of Physics Inc.
Related Researcher
  • Author Kim, Hoe Joon Nano Materials and Devices Lab
  • Research Interests MEMS/NEMS; Micro/Nano Sensors; Piezoelectric Devices; Nanomaterials; Heat Transfer; Atomic Force Microscope
